YAMAHA RX-A6A (B) AV Receiver

Pure power and precision. The A6A has been carefully designed so every element of your entertainment is the best it can be. From slight whispers of sound to swift on-screen movements, the A6A ensures you won’t miss a thing.

BREATHTAKING SOUND
SURROUND:AI™

Analyses the scene of the contents and optimizes the surround effect of distinct sound elements such as background music, dialogue, and sound effects. It’s like having a professional sound engineer tune the sound according to the scene. 64-bit processing with Qualcomm® QCS407.

Crafted for Clarity

The newly designed Anti Resonance Technology (A.R.T.), H-shaped Cross Frame and mechanical structure are a rock-solid defense against internal and external vibrations that affect the sound. Experience crystal clear sound that moves you, all while your AV receiver stays perfectly still.

High-Quality Digital Components

Qualcomm® QCS407 takes your AV receiver’s surround sound to the next level with support for Dolby Atmos® and DTS:X®. With SABRE ES9007S Premier Audio DAC, you get extraordinary signal-to-noise ratio and high dynamic range for professional quality audio.

MOVIES AND GAMES LIKE NEVER BEFORE

MusicCast App

Explore the power of multi-room audio, access your sources and streaming devices, and control your AV receiver, all through your smartphone.

Voice Control

Works with Alexa and Google Assistant, so your AV receiver is always at your command. Through AirPlay 2, you can stream your music via voice control operation Siri from Apple iOS device. *Availability varies by region.

AV Setup Guide App

Offers expert guidance through installation, cable connections, and various other settings.

DESIGNED FOR YOUR SPACE
YPAO™-R.S.C. with multi-point measurement and precision EQ

Calibrates sound to your room by analyzing room acoustics and measuring speaker characteristics. This feature also optimizes sound parameters for maximum performance from SURROUND:AI™, Dolby Atmos® and DTS:X®.

Compatible with Wireless Rear Speaker

Gives you the freedom to arrange your rear speakers wirelessly to suit your home decor by adding Yamaha wireless speaker MusicCast 20 or MusicCast 50.

Dynamic and Compelling Design

Classic Yamaha craftsmanship meets cutting-edge design. Every piece has been carefully crafted to ensure this AV receiver looks and sounds perfect in your home.

Specifications:

• Channel: 9.2
• Rated Output Power :(1kHz, 1ch driven) 185 W (8 ohms, 0.9% THD)
• Rated Output Power (:20Hz-20kHz, 2ch driven) 150 W (8 ohms, 0.06% THD)
• Maximum Effective Output Power :(1kHz, 1ch driven) 220 W (8 ohms, 10% THD)
• High Slew Rate Amplifier :Yes
• Surround Sound Processing
• Surround:AI: Yes
• CINEMA DSP :Yes (HD3)
• DSP Programs :24
• Dialog Level Adjustment :Yes
• Virtual Presence Speaker :Yes
• Virtual Surround Back Speaker :Yes
• Dialogue Lift :Yes
• SILENT CINEMA / Virtual CINEMA DSP: Yes
• Dolby Atmos Y:es
• Dolby Atmos Height Virturalizer :Yes (via future update)
• Dolby TrueHD :Yes
• Dolby Digital Plus :Yes
• Dolby Surround :Yes
• DTS:X :Yes
• DTS-HD Master Audio :Yes
• Auro 3D : Yes
• Audio Features
• File Format MP3 / WMA / MPEG-4 AAC, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz
• Pure Direct :Yes
• Compressed Music Enhancer :Yes
• High-resolution Music Enhancer :Yes
• YPAO multi-point measurement: Yes with R.S.C. (Reflected Sound Control) , 3D, 64-bit High Precision EQ CalculationYes
• YPAO Volume :Yes
• Adaptive DRC (Dynamic Range Control) :Yes
• Initial Volume & Maximum Volume Setting :Yes
• A.R.T. Wedge :Yes
• Bi-amp capability :Yes
• Audio Delay :Yes (0-500 ms)
• DA Converter : 384 kHz / 32-bit ESS Hyperstream DAC ES9026PRO x1 ES9007S x1
• Video Features
• HDMI eARC :Yes
• HDMI Audio Return Channel :Yes
• HDMI Pass-through: 8K60B, 4K120AB (via future update)
• HDMI Up-scaling: Yes up to 8K
• HDMI Up-conversion :Yes (Analog to HDMI)
• Dolby Vision :Yes
• HDR 10+ :Yes (via future update)
• VRR/ALLM/QMS/QFT :Yes (via future update)
• Video adjustment :N/A
• Connectivity
• MusicCast Surround :Yes
• HDMI Input/Output: 7 / 3 (HDMI2.1 / HDCP2.3)
• HDMI CEC :Yes
• USB Input :Yes
• Network Port :Yes
• Wi-Fi :mYes (2.4 / 5 GHz)
• AirPlay 2 :Yes
• Bluetooth :Yes (SBC / AAC)
• Front AV Input USB
• Digital Audio Input/Output Optical : 2 / 0
• Digital Audio Input/Output  Coaxial 1 / 0
• Analog Audio Input/Output : 4 / 0
• Phono Input : Yes
• XLR Terminal : N/A
• Component Video Input/Output : 1/0
• Composite Video Input/Output : 2/0
• Preout : 11.2-ch
• Headphone Output : 1
• Tuner Section FM/AM Tuner Yes (Availability varies by region.)
• DAB Tuner Yes (Availability varies by region.)
• User Interface
• On-screen display : Graphical User Interface
• SCENE :  SCENE PLUS (8 sets)
• App Control : Yes (iPhone / iPad / Android phone / tablet)
• Web Browser Control :Yes
• Remote Control Unit : Yes
• Zone 2 Audio Output : Preout / HDMI
• Zone 3 Audio Output :Preout
• Zone 4 Audio Output : HDMI
• Powered Zone :  Zone 2/3
• Zone Video Output :HDMI
• Zone B Output : HDMI
• Zone GUI : Yes
• RS-232C Interface :N/A
• +12V Trigger Output : 2
• Remote (IR) Input/Output : 1 / 1
• Party Mode :Yes
• General
• Standby Power Consumption (IR only) : <0.4 W
• Auto Power Standby  :Yes
• ECO mode  :Yes
• Dimensions (W x H x D) : 435 W x 192 H x 442 D mm (with antenna up:435W x 271H x 442D mm); 17-1/8"W x 7-1/2"H x 17-3/8"D (with antenna up:17-1/8"W x 10-5/8"H x 17-3/8"D)
• Weight :20.3 kg; 44.8 lbs. (Varies by region)
